The DJI Matrice 4 Enterprise packs a 48MP 168mm tele camera into a 1.2 kg airframe, yet offshore blade inspection in Taiwan still belongs to heavier dronesDJI Matrice 4 Enterprise 將 48MP 168mm 長焦相機裝入 1.2 公斤機身,然而台灣離岸風機葉片檢測仍屬於重型無人機的天下DJI Matrice 4 Enterpriseは1.2kgの機体に48MP 168mm望遠カメラを搭載しているが、台湾の洋上ブレード検査は依然としてより重いドローンに頼っている

The DJI Matrice 4 Enterprise packs a 48MP 168mm tele camera into a 1.2 kg airframe, yet offshore blade inspection in Taiwan still belongs to heavier drones
Quick answer: The DJI Matrice 4 Enterprise is a strong inspection drone for towers, substations, solar farms and onshore turbine pre-screening: 49 minutes of flight, a 48MP 168mm tele camera and a laser rangefinder in a 1.2 kg airframe. For offshore wind blade inspection, the Matrice 350 RTK class still wins on weather sealing and payload.

The DJI Matrice 4 Enterprise packs a 48MP 168mm tele camera into a 1.2 kg airframe, yet offshore blade inspection in Taiwan still belongs to heavier drones

The DJI Matrice 4 Enterprise is the most capable compact inspection drone DJI has shipped, and I still wouldn't send it to a wind turbine blade off the Taiwan coast. On paper, its 48MP 168mm tele camera resolves about half a millimetre per pixel at 20 m. Offshore, the things that decide whether you bring home usable data are sensor size, airframe mass and weather sealing.

I inspect onshore and offshore wind turbine blades in Taiwan for a living, and I build AI tools that turn inspection images into reports. That means I judge the Matrice 4 series on two things: what it catches in the air, and what it does to the pipeline after landing.

Here's where it earns a place in the case, and where it doesn't.

What is the DJI Matrice 4 Enterprise built for?

The Matrice 4 series is DJI's compact multi-sensor platform for inspection, mapping and public safety. It fills the slot the Mavic 3 Enterprise used to hold, with more camera. You unfold it, launch it in a couple of minutes, and get wide, medium tele and long tele imagery plus a laser rangefinder from one gimbal.

The headline specs, from DJI's published sheets:

  • Up to 49 minutes of flight time and around 42 minutes of hover, in still air
  • Wind resistance rated to 12 m/s
  • Three visible cameras: wide, 70mm medium tele and 168mm tele (35mm equivalent)
  • A laser rangefinder that measures distance to the target
  • O4 Enterprise transmission, with the 4T adding a 640 x 512 thermal core

For telecom towers, substations, transmission lines and solar farms, that package is hard to argue with. One person can carry it, fly it and cover an asset that used to need a heavier drone and a second pilot.

The DJI Matrice 4 Enterprise packs a 48MP 168mm tele camera into a 1.2 kg airframe, yet offshore blade inspection in Taiwan still belongs to heavier drones

How do the Matrice 4E and Matrice 4T differ for inspection?

Pick the 4E for mapping and visual detail. Pick the 4T when heat tells the story. The airframe is the same and the payload decides the job.

SpecMatrice 4EMatrice 4TMatrice 350 RTK (reference)
Takeoff weightAbout 1.2 kgAbout 1.2 kgAbout 6.5 kg without payload
Max flight time49 min49 min55 min without payload
Wide camera20MP 4/3 CMOS, mechanical shutter48MP 1/1.3 inch CMOSSwappable Zenmuse payload
Tele cameras48MP 70mm + 48MP 168mm48MP 70mm + 48MP 168mmDepends on payload (H20T, H30T, P1)
ThermalNone640 x 512, 1280 x 1024 in high-res mode640 x 512 (H20T) or 1280 x 1024 (H30T)
Weather sealingNo IP rating listedNo IP rating listedIP55
Best fitMapping, photogrammetry, visual inspectionSolar, substations, electrical faultsOffshore blades, heavy payloads, bad weather

The 4E's mechanical shutter matters for photogrammetry because fast mapping passes come back without rolling-shutter distortion. The 4T's thermal core is the reason solar crews buy it. A hot cell or a failed bypass diode shows up in a single pass.

Can the DJI Matrice 4 inspect wind turbine blades?

Yes, onshore and in calm conditions, and it does better than most people expect. Offshore, I'd keep it as a backup and a quick pre-screen tool.

The pixel math

Blade inspection comes down to ground sampling distance, meaning how many millimetres of blade surface one pixel covers. Take the 168mm-equivalent tele. Its horizontal field of view is about 12 degrees, so at a 20 m standoff it covers roughly 4.3 m of blade. Spread that over a 48MP frame about 8,000 pixels wide and you get around 0.5 mm per pixel. In 12MP binned mode, it's around 1 mm per pixel.

Now take a full-frame 45MP camera with a 50mm lens at the same distance. That works out to roughly 1.8 mm per pixel. On a spreadsheet, the little drone wins.

What the math leaves out

There are three things the spec sheet can't show you.

Sensor area. The tele camera sits on a 1/1.5 inch sensor. A full-frame sensor has around 15 times the area and collects far more light per frame. Offshore light is often flat grey with salt haze, and blades are white composite. A small sensor forces a higher ISO or a slower shutter, and either one softens the edge of a hairline crack.

Mass in gusts. The Matrice 4 and the 350 RTK carry the same 12 m/s wind rating. That rating tells you the drone can hold position. It tells you nothing about whether a 168mm frame stays sharp when a gust rolls off a spinning-down rotor. A 1.2 kg airframe gets pushed around more than a 6.5 kg one, and at long focal lengths small movements turn into motion blur.

Weather sealing. The 350 RTK is rated IP55. I can't find an IP rating for the Matrice 4 in DJI's published specs. Offshore, spray and passing drizzle are normal working conditions, and losing a short weather window to a grounded drone costs more than the drone itself.

My read: the Matrice 4 tele gets you detail and the heavier platform gets you consistency. A blade dataset has to cover 3 blades on 4 faces each (leading edge, trailing edge, pressure side, suction side), and it's only usable if every frame holds up.

In my experience, the defect that slips through most often is fine cracking along the trailing edge bond line, especially on the face turned away from the sun. Catching it needs a steady frame and even exposure, and that's exactly where small sensors struggle.

Where does the Matrice 4 beat a Matrice 350 RTK?

In plenty of places. The heavy drone has real limits too.

  1. Time to first flight. It goes from car boot to airborne in minutes. The 350 RTK needs payload mounting, dual batteries and more deck space.
  2. Onshore blade pre-screening. Before you book a full inspection, a quick pass with the 168mm tele shows which turbines need a closer look.
  3. Solar farms. The 4T's thermal camera plus a mapping mission covers a utility-scale site in fewer flights with a fraction of the kit.
  4. Tower and nacelle exterior checks. Laser rangefinder coordinates let you log where a defect sits without guessing.
  5. Travel. For a solo operator flying to jobs, one hard case beats two. I'm planning work in Japan, where transport and site access costs add up fast, so this one matters to me.
  6. Cost per flight hour. Batteries and airframe are cheaper, and so is a bad day.

For a small team, a sensible fleet is one heavy, sealed platform for offshore and bad weather, plus one Matrice 4 for everything else.

Why does the report pipeline matter as much as the drone?

The client pays for the report. A full wind farm campaign produces thousands of images, and each defect has to be sorted, tagged, measured and graded by severity. That work usually takes longer than the flying.

That's where most of my time goes now. Here's my current workflow:

  • Images come off the drone with GPS, gimbal angle and laser range data in the metadata
  • A script groups them by turbine, blade and face
  • An AI model does a first pass, flags likely defects and suggests a category (erosion, crack, lightning damage, contamination)
  • A human inspector reviews every flag and sets the final severity
  • A draft report is built from the reviewed data

The Matrice 4's laser rangefinder data fits this pipeline well because distance to target lets you convert pixels into real defect sizes. That alone is a reason to own one, even if it never flies offshore.

One rule I don't bend: inspection imagery belongs to the asset owner. Any AI processing runs only on data you have the rights to process, and it's stored where the client expects it. Uploading to the cloud by default is a contract problem waiting to happen.

What should you check before flying a Matrice 4 in Taiwan or Japan?

In both countries: register the aircraft, hold the right licence class and confirm the flight zone before the job.

Taiwan. Drones of 250 g and above must be registered with the Civil Aeronautics Administration, and commercial operators need the matching operator licence. Flights near airports, ports and restricted areas need prior approval. Offshore work adds maritime coordination on top of that.

Japan. Under MLIT rules, drones of 100 g and above need registration and Remote ID, and the national first-class and second-class pilot certificates cover higher-risk flights. Japanese operations are my next step, so I'm following this closely. If you're planning work there, budget time for paperwork before you budget for hardware.

Check your data settings too. DJI Pilot 2 has a Local Data Mode that stops the app from connecting to the internet during flight. Turn it on for any client work.

My verdict on the Matrice 4 for enterprise inspection

Buy the Matrice 4T if your work is solar, substations, towers or onshore turbine pre-screening. Buy the 4E if you map. For offshore blade inspection in Taiwan's conditions, keep a heavier, sealed platform as your primary aircraft and use the Matrice 4 as the fast second drone.

Put as much effort into the reporting pipeline as into the hardware. That's where the days go, and it's where AI now gives them back.

快速解答: DJI Matrice 4 Enterprise 是一款強大的檢測無人機,適用於電塔、變電站、太陽能電廠和陸上風機的初步篩檢:它擁有 49 分鐘的飛行時間、48MP 168mm 長焦相機和雷射測距儀,全部裝載於 1.2 公斤的機身中。然而,對於離岸風機葉片檢測,Matrice 350 RTK 等級的無人機在耐候性和酬載能力方面仍佔優勢。

DJI Matrice 4 Enterprise 將 48MP 168mm 長焦相機裝入 1.2 公斤機身,然而台灣離岸風機葉片檢測仍屬於重型無人機的天下

DJI Matrice 4 Enterprise 是 DJI 推出過功能最強大的輕巧型檢測無人機,但我仍然不會將它派往台灣海岸線外的風力發電機葉片進行作業。從規格上看,其 48MP 168mm 長焦相機在 20 公尺距離下,每個像素約可解析半毫米。但在離岸作業中,決定您能否帶回可用數據的因素是感光元件尺寸、機身質量和耐候性。

我在台灣從事陸上和離岸風力發電機葉片檢測工作,並開發將檢測影像轉化為報告的 AI 工具。這意味著我會從兩個方面來評估 Matrice 4 系列:它在空中捕捉到的資訊,以及降落後對後續流程的影響。

以下是它值得佔有一席之地的地方,以及它力有未逮之處。

DJI Matrice 4 Enterprise 的設計用途是什麼?

Matrice 4 系列是 DJI 針對檢測、測繪和公共安全領域推出的輕巧型多感測器平台。它取代了 Mavic 3 Enterprise 曾經佔據的位置,並配備了更強大的相機。您只需將其展開,幾分鐘內即可升空,並從單一雲台上獲得廣角、中長焦和長焦影像,以及雷射測距儀功能。

以下是 DJI 公布的主要規格:

  • 在靜風條件下,飛行時間最長可達 49 分鐘,懸停時間約 42 分鐘
  • 抗風等級達 12 m/s
  • 三個可見光相機:廣角、70mm 中長焦和 168mm 長焦(35mm 等效焦距)
  • 可測量目標距離的雷射測距儀
  • O4 Enterprise 圖傳系統,4T 版本額外搭載 640 x 512 熱成像核心

對於電信塔、變電站、輸電線路和太陽能電廠而言,這樣的組合無可挑剔。一個人就能攜帶、操作它,並完成過去需要更重型無人機和第二名飛手才能覆蓋的資產檢測。

DJI Matrice 4 Enterprise 將 48MP 168mm 長焦相機裝入 1.2 公斤機身,然而台灣離岸風機葉片檢測仍屬於重型無人機的天下

Matrice 4E 和 Matrice 4T 在檢測方面有何不同?

選擇 4E 用於測繪和視覺細節檢測。當熱能是關鍵資訊時,則選擇 4T。兩者的機身相同,但酬載決定了其用途。

規格Matrice 4EMatrice 4TMatrice 350 RTK (參考)
起飛重量約 1.2 公斤約 1.2 公斤約 6.5 公斤 (不含酬載)
最長飛行時間49 分鐘49 分鐘55 分鐘 (不含酬載)
廣角相機20MP 4/3 CMOS,機械快門48MP 1/1.3 吋 CMOS可更換 Zenmuse 酬載
長焦相機48MP 70mm + 48MP 168mm48MP 70mm + 48MP 168mm視酬載而定 (H20T, H30T, P1)
熱成像無640 x 512,高解析度模式下為 1280 x 1024640 x 512 (H20T) 或 1280 x 1024 (H30T)
耐候性未列出 IP 等級未列出 IP 等級IP55
最佳適用測繪、攝影測量、視覺檢測太陽能、變電站、電氣故障離岸葉片、重型酬載、惡劣天氣

4E 的機械快門對於攝影測量很重要,因為快速測繪飛行不會產生果凍效應失真。4T 的熱成像核心是太陽能團隊購買它的原因。一個過熱的電池片或失效的旁路二極體在一次飛行中就能顯現出來。

DJI Matrice 4 能否檢測風力發電機葉片?

可以,在陸上和風平浪靜的條件下,它的表現比大多數人預期的要好。在離岸作業中,我會將它作為備用機和快速初步篩檢工具。

像素計算

葉片檢測的關鍵在於地面採樣距離 (GSD),也就是一個像素能覆蓋多少毫米的葉片表面。以 168mm 等效焦距的長焦相機為例。其水平視角約為 12 度,因此在 20 公尺的距離下,它大約能覆蓋 4.3 公尺的葉片。將其分佈在約 8,000 像素寬的 48MP 畫面中,您將獲得約每像素 0.5 毫米的解析度。在 12MP 像素合併模式下,約為每像素 1 毫米。

現在,假設一台全片幅 45MP 相機搭配 50mm 鏡頭在相同距離下拍攝。其解析度約為每像素 1.8 毫米。從數據上看,這款小型無人機勝出。

數據未揭示的真相

有三件事是規格表無法告訴您的。

  • 感光元件面積。 長焦相機搭載 1/1.5 吋感光元件。全片幅感光元件的面積約是其 15 倍,每幀能收集更多光線。離岸光線常因鹽霧而呈現灰濛濛一片,而葉片是白色複合材料。小型感光元件會迫使您使用更高的 ISO 或更慢的快門,這兩者都會使髮絲裂紋的邊緣變得模糊。
  • 陣風中的質量。 Matrice 4 和 350 RTK 都具備 12 m/s 的抗風等級。這個等級告訴您無人機可以保持位置。但它沒有告訴您,當陣風從正在減速的旋翼上吹過時,168mm 焦距的畫面是否能保持清晰。1.2 公斤的機身比 6.5 公斤的機身更容易被風吹動,而在長焦距下,微小的移動都會導致動態模糊。
  • 耐候性。 350 RTK 具備 IP55 等級。我在 DJI 公布的規格中找不到 Matrice 4 的 IP 等級。在離岸作業中,水花和陣雨是正常的工作條件,而因為無人機停飛而錯失短暫的良好天氣窗口,其成本會比無人機本身更高。

我的看法是:Matrice 4 的長焦相機提供細節,而較重的平台則提供一致性。一個葉片數據集必須涵蓋 3 片葉片,每片葉片有 4 個面(前緣、後緣、受壓面、吸力面),而且只有當每個畫面都清晰可用時,數據集才算有用。

根據我的經驗,最常被遺漏的缺陷是沿著後緣接合線的細微裂紋,尤其是在背對太陽的一面。捕捉這些裂紋需要穩定的畫面和均勻的曝光,而這正是小型感光元件的弱點。

Matrice 4 在哪些方面勝過 Matrice 350 RTK?

在許多方面。重型無人機也有其真正的限制。

  1. 首次飛行時間。 它可以在幾分鐘內從汽車後備箱升空。350 RTK 需要安裝酬載、雙電池和更多的甲板空間。
  2. 陸上葉片初步篩檢。 在預訂全面檢測之前,使用 168mm 長焦相機快速掃描可以顯示哪些風機需要仔細檢查。
  3. 太陽能電廠。 4T 的熱成像相機加上測繪任務,可以用更少的飛行次數和更少的設備覆蓋公用事業規模的場地。
  4. 塔架和機艙外部檢查。 雷射測距儀的座標讓您可以精確記錄缺陷位置,無需猜測。
  5. 旅行。 對於單獨執行任務的操作員來說,一個硬殼箱比兩個更好。我正在規劃在日本的工作,那裡的交通和場地進入成本迅速累積,所以這一點對我來說很重要。
  6. 每飛行小時成本。 電池和機身更便宜,即使是糟糕的一天也一樣。

對於小型團隊而言,合理的機隊配置是一台用於離岸和惡劣天氣的重型密封平台,再加上一台 Matrice 4 用於其他所有任務。

為何報告流程與無人機本身同樣重要?

客戶支付的是報告。一次完整的風電場檢測任務會產生數千張影像,每個缺陷都必須進行分類、標記、測量並按嚴重程度分級。這項工作通常比飛行本身耗時更久。

這就是我目前大部分時間的投入之處。以下是我的當前工作流程:

  • 影像從無人機下載後,其元數據中包含 GPS、雲台角度和雷射測距數據
  • 一個腳本會將它們按風機、葉片和面進行分組
  • AI 模型進行首次篩選,標記可能的缺陷並建議類別(侵蝕、裂紋、雷擊損傷、污染)
  • 人工檢測員審查每個標記並設定最終嚴重程度
  • 從審查後的數據建立報告草稿

Matrice 4 的雷射測距儀數據非常適合這個流程,因為目標距離可以讓您將像素轉換為實際的缺陷尺寸。僅憑這一點,就足以成為擁有一台的理由,即使它從未在離岸作業中使用。

我有一個不容妥協的原則:檢測影像屬於資產所有者。任何 AI 處理都只能在您有權處理的數據上運行,並且必須儲存在客戶預期的位置。預設上傳到雲端可能會導致合約問題。

在台灣或日本飛行 Matrice 4 之前應檢查什麼?

在這兩個國家:在執行任務前,請註冊飛行器、持有正確的執照類別並確認飛行區域。

台灣。 250 克及以上的無人機必須向民航局註冊,商業操作員需要相應的操作執照。機場、港口和限制區域附近的飛行需要事先批准。離岸作業在此基礎上還需額外進行海事協調。

日本。 根據國土交通省 (MLIT) 規定,100 克及以上的無人機需要註冊和遠端識別,國家一級和二級飛行員證書涵蓋了高風險飛行。在日本的業務是我的下一步,所以我正密切關注。如果您計劃在那裡工作,請在預算硬體之前,先為文書工作預留時間。

也請檢查您的數據設定。DJI Pilot 2 具有本地數據模式,可阻止應用程式在飛行期間連接到互聯網。對於任何客戶工作,請務必開啟此模式。

我對 Matrice 4 企業級檢測的評價

如果您的工作是太陽能、變電站、電塔或陸上風機的初步篩檢,請購買 Matrice 4T。如果您主要進行測繪,請購買 4E。對於台灣條件下的離岸葉片檢測,請將更重、密封的平台作為您的主要飛行器,並將 Matrice 4 作為快速的備用無人機。

投入與硬體同樣多的精力在報告流程上。時間都花在那裡了,而現在 AI 正在將它們還給您。

簡単な回答: DJI Matrice 4 Enterpriseは、タワー、変電所、ソーラーファーム、陸上タービンの事前スクリーニングに強力な検査ドローンです。1.2kgの機体に49分の飛行時間、48MP 168mm望遠カメラ、レーザー距離計を搭載しています。洋上風力ブレード検査では、Matrice 350 RTKクラスが耐候性とペイロードで依然として優位です。

DJI Matrice 4 Enterpriseは1.2kgの機体に48MP 168mm望遠カメラを搭載しているが、台湾の洋上ブレード検査は依然としてより重いドローンに頼っている

DJI Matrice 4 Enterpriseは、DJIがこれまでに送り出した中で最も高性能なコンパクト検査ドローンですが、私はこれを台湾沖の風力タービンブレード検査には送りません。スペック上では、その48MP 168mm望遠カメラは20mの距離で約0.5ミリメートル/ピクセルの解像度を実現します。しかし洋上では、使用可能なデータを持ち帰れるかどうかを決定するのは、センサーサイズ、機体質量、そして耐候性です。

私は台湾で陸上および洋上風力タービンブレードの検査を生業としており、検査画像をレポートに変換するAIツールを開発しています。そのため、Matrice 4シリーズを2つの点から評価します。空中で何が捉えられるか、そして着陸後にパイプラインにどう影響するかです。

ここでは、それが役立つ場面と、そうでない場面を説明します。

DJI Matrice 4 Enterpriseは何のために作られたのか?

Matrice 4シリーズは、DJIの検査、マッピング、公共安全向けのコンパクトなマルチセンサープラットフォームです。Mavic 3 Enterpriseが担っていた役割を、より高性能なカメラで引き継ぎます。数分で展開して離陸させることができ、1つのジンバルから広角、中望遠、長望遠の画像とレーザー距離計を利用できます。

DJIが公開している主要スペックは以下の通りです。

  • 静止空気下で最大49分の飛行時間、約42分のホバリング時間
  • 耐風性能は12 m/s
  • 3つの可視カメラ:広角、70mm中望遠、168mm望遠(35mm換算)
  • ターゲットまでの距離を測定するレーザー距離計
  • O4 Enterprise伝送、4Tは640 x 512のサーマルコアを追加

通信タワー、変電所、送電線、ソーラーファームにとって、このパッケージは申し分ありません。一人で持ち運び、飛行させ、以前はより重いドローンと二人目のパイロットが必要だった資産をカバーできます。

DJI Matrice 4 Enterpriseは1.2kgの機体に48MP 168mm望遠カメラを搭載しているが、台湾の洋上ブレード検査は依然としてより重いドローンに頼っている

Matrice 4EとMatrice 4Tは検査においてどう違うのか?

マッピングや視覚的な詳細には4Eを選びましょう。熱が重要な場合は4Tを選びます。機体は同じで、ペイロードが用途を決定します。

スペックMatrice 4EMatrice 4TMatrice 350 RTK (参考)
離陸重量約1.2 kg約1.2 kgペイロードなしで約6.5 kg
最大飛行時間49分49分ペイロードなしで55分
広角カメラ20MP 4/3 CMOS、メカニカルシャッター48MP 1/1.3インチ CMOS交換可能なZenmuseペイロード
望遠カメラ48MP 70mm + 48MP 168mm48MP 70mm + 48MP 168mmペイロードによる (H20T, H30T, P1)
サーマルなし640 x 512、高解像度モードで1280 x 1024640 x 512 (H20T) または 1280 x 1024 (H30T)
耐候性IP等級の記載なしIP等級の記載なしIP55
最適な用途マッピング、写真測量、目視検査太陽光発電、変電所、電気的故障洋上ブレード、重いペイロード、悪天候

4Eのメカニカルシャッターは、高速マッピング時にローリングシャッター歪みなしで画像が得られるため、写真測量において重要です。4Tのサーマルコアは、太陽光発電の作業員が購入する理由です。高温セルや故障したバイパスダイオードは、一度の飛行で検出できます。

DJI Matrice 4は風力タービンブレードを検査できるか?

はい、陸上および穏やかな条件下であれば可能ですし、ほとんどの人が期待する以上の性能を発揮します。洋上では、バックアップおよび迅速な事前スクリーニングツールとして使うでしょう。

ピクセル計算

ブレード検査は、地上画素寸法(GSD)に帰着します。つまり、1ピクセルがブレード表面の何ミリメートルをカバーするかということです。168mm相当の望遠カメラを例にとると、その水平画角は約12度なので、20mの距離ではブレードの約4.3mをカバーします。これを幅約8,000ピクセルの48MPフレームに広げると、約0.5mm/ピクセルになります。12MPビニングモードでは、約1mm/ピクセルです。

次に、同じ距離で50mmレンズを搭載したフルフレーム45MPカメラを考えてみましょう。これは約1.8mm/ピクセルになります。スプレッドシート上では、小型ドローンが優位に立ちます。

計算が省いているもの

スペックシートには現れない3つの要素があります。

センサー面積。 望遠カメラは1/1.5インチセンサーに搭載されています。フルフレームセンサーは面積が約15倍あり、1フレームあたりはるかに多くの光を収集します。洋上では、光は塩霧でしばしば平坦な灰色になり、ブレードは白い複合材です。小さなセンサーはISOを高くするかシャッタースピードを遅くすることを余儀なくされ、どちらもヘアラインクラックの縁をぼやけさせます。 突風時の質量。 Matrice 4と350 RTKは同じ12 m/sの耐風性能を持っています。この評価はドローンが位置を保持できることを示しますが、回転が停止しつつあるローターから突風が吹き付けたときに168mmフレームがシャープさを保てるかどうかについては何も示しません。1.2kgの機体は6.5kgの機体よりも揺さぶられやすく、長い焦点距離ではわずかな動きがモーションブラーに変わります。 耐候性。 350 RTKはIP55等級です。DJIの公開スペックではMatrice 4のIP等級を見つけることができません。洋上では、しぶきや通り雨は通常の作業条件であり、短い好天の窓をドローンの故障で失うことは、ドローン自体の費用よりも高くつきます。

私の見解では、Matrice 4の望遠カメラは詳細を提供し、より重いプラットフォームは一貫性を提供します。ブレードのデータセットは、3枚のブレードの各4面(前縁、後縁、圧力面、吸引面)をカバーする必要があり、すべてのフレームがしっかりしていなければ使用できません。

私の経験では、最も見落とされがちな欠陥は、後縁の接着線に沿った微細なひび割れ、特に太陽から遠い面に見られるものです。これを捉えるには、安定したフレームと均一な露出が必要であり、まさに小型センサーが苦戦する点です。

Matrice 4がMatrice 350 RTKに勝る点はどこか?

多くの点で優れています。重いドローンにも実際の限界があります。

  1. 初飛行までの時間。 車のトランクから数分で離陸できます。350 RTKはペイロードの取り付け、デュアルバッテリー、より広いデッキスペースが必要です。
  2. 陸上ブレードの事前スクリーニング。 本格的な検査を予約する前に、168mm望遠カメラで素早く飛行させることで、どのタービンを詳しく見る必要があるかを示します。
  3. ソーラーファーム。 4Tのサーマルカメラとマッピングミッションを組み合わせることで、大規模なサイトを少ない飛行回数で、かつ少ない機材でカバーできます。
  4. タワーとナセルの外観チェック。 レーザー距離計の座標により、欠陥の位置を推測することなく記録できます。
  5. 移動。 仕事のために飛行する単独オペレーターにとって、ハードケース1つは2つよりも優れています。私は日本での仕事を計画しており、交通費や現場へのアクセス費用がすぐに膨らむため、この点は私にとって重要です。
  6. 飛行時間あたりのコスト。 バッテリーと機体は安価であり、万が一の事態もより安価に済みます。

小規模なチームにとって、賢明な機材構成は、洋上や悪天候用の重くて密閉されたプラットフォーム1機と、それ以外のすべてに対応するMatrice 4を1機持つことです。

なぜレポートパイプラインはドローンと同じくらい重要なのか?

クライアントはレポートに対して料金を支払います。風力発電所の完全なキャンペーンでは何千もの画像が生成され、各欠陥は分類、タグ付け、測定、深刻度による評価が必要です。この作業は通常、飛行よりも時間がかかります。

現在、私の時間のほとんどがここに費やされています。私の現在のワークフローは以下の通りです。

  • 画像はGPS、ジンバル角度、レーザー距離データがメタデータに含まれた状態でドローンから取り出されます
  • スクリプトがそれらをタービン、ブレード、面ごとにグループ化します
  • AIモデルが最初のパスを実行し、可能性のある欠陥にフラグを立て、カテゴリ(浸食、ひび割れ、落雷損傷、汚染)を提案します
  • 人間検査員がすべてのフラグを確認し、最終的な深刻度を設定します
  • 確認されたデータからレポートのドラフトが作成されます

Matrice 4のレーザー距離計データは、ターゲットまでの距離によってピクセルを実際の欠陥サイズに変換できるため、このパイプラインによく適合します。洋上で飛行させないとしても、これだけでも所有する理由になります。

私が曲げないルールが一つあります。検査画像は資産所有者に帰属します。AI処理は、処理する権利を持つデータに対してのみ実行され、クライアントが期待する場所に保存されます。デフォルトでクラウドにアップロードすることは、契約上の問題を引き起こす可能性があります。

台湾や日本でMatrice 4を飛行させる前に確認すべきこと

両国で共通して:機体を登録し、適切なライセンスクラスを保持し、作業前に飛行区域を確認してください。

台湾。

250g以上のドローンは民用航空局に登録する必要があり、商業運航者は対応する運航者ライセンスが必要です。空港、港湾、制限区域付近での飛行には事前の承認が必要です。洋上での作業には、さらに海上調整が加わります。

日本。

国土交通省の規則では、100g以上のドローンは登録とリモートIDが必要であり、国家の第一種および第二種操縦者技能証明は高リスクの飛行をカバーします。日本での運用は私の次のステップなので、これを注意深く追っています。もしそこで作業を計画しているなら、ハードウェアの予算を立てる前に書類作成のための時間を確保してください。

データ設定も確認してください。DJI Pilot 2には、飛行中にアプリがインターネットに接続するのを停止するローカルデータモードがあります。クライアントの作業では必ずこれをオンにしてください。

エンタープライズ検査におけるMatrice 4の私の評価

あなたの仕事が太陽光発電、変電所、タワー、または陸上タービンの事前スクリーニングであればMatrice 4Tを購入してください。マッピングを行う場合は4Eを購入してください。台湾の条件下での洋上ブレード検査では、より重く密閉されたプラットフォームを主機として維持し、Matrice 4を高速なセカンドドローンとして使用してください。

ハードウェアと同じくらい、レポートパイプラインにも力を入れてください。そこに多くの時間が費やされますが、AIが今、その時間を取り戻してくれます。

Frequently asked questions常見問題よくある質問

Is the DJI Matrice 4T good for solar farm inspection?Is the DJI Matrice 4T good for solar farm inspection?Is the DJI Matrice 4T good for solar farm inspection?
Yes. The 4T pairs a 640 x 512 thermal camera (1280 x 1024 in high-res mode) with a 48MP wide camera and up to 49 minutes of flight. Hot cells, failed bypass diodes and string faults show up clearly, and one pilot can cover a utility-scale site with far less kit than a Matrice 350 RTK setup.Yes. The 4T pairs a 640 x 512 thermal camera (1280 x 1024 in high-res mode) with a 48MP wide camera and up to 49 minutes of flight. Hot cells, failed bypass diodes and string faults show up clearly, and one pilot can cover a utility-scale site with far less kit than a Matrice 350 RTK setup.Yes. The 4T pairs a 640 x 512 thermal camera (1280 x 1024 in high-res mode) with a 48MP wide camera and up to 49 minutes of flight. Hot cells, failed bypass diodes and string faults show up clearly, and one pilot can cover a utility-scale site with far less kit than a Matrice 350 RTK setup.
What is the difference between the Matrice 4E and Matrice 4T?What is the difference between the Matrice 4E and Matrice 4T?What is the difference between the Matrice 4E and Matrice 4T?
Both use the same airframe with 70mm and 168mm 48MP tele cameras and a laser rangefinder. The 4E adds a 20MP 4/3 wide camera with a mechanical shutter, which suits mapping and photogrammetry. The 4T swaps that for a 48MP wide camera and a thermal core, which suits electrical, solar and substation work.Both use the same airframe with 70mm and 168mm 48MP tele cameras and a laser rangefinder. The 4E adds a 20MP 4/3 wide camera with a mechanical shutter, which suits mapping and photogrammetry. The 4T swaps that for a 48MP wide camera and a thermal core, which suits electrical, solar and substation work.Both use the same airframe with 70mm and 168mm 48MP tele cameras and a laser rangefinder. The 4E adds a 20MP 4/3 wide camera with a mechanical shutter, which suits mapping and photogrammetry. The 4T swaps that for a 48MP wide camera and a thermal core, which suits electrical, solar and substation work.
Can the DJI Matrice 4 fly in rain or offshore spray?Can the DJI Matrice 4 fly in rain or offshore spray?Can the DJI Matrice 4 fly in rain or offshore spray?
I can't find an IP rating for the Matrice 4 in DJI's published specs, so I wouldn't count on it in rain or heavy spray. For offshore work, where drizzle and salt spray are routine, an IP55-rated platform like the Matrice 350 RTK is the safer primary aircraft.I can't find an IP rating for the Matrice 4 in DJI's published specs, so I wouldn't count on it in rain or heavy spray. For offshore work, where drizzle and salt spray are routine, an IP55-rated platform like the Matrice 350 RTK is the safer primary aircraft.I can't find an IP rating for the Matrice 4 in DJI's published specs, so I wouldn't count on it in rain or heavy spray. For offshore work, where drizzle and salt spray are routine, an IP55-rated platform like the Matrice 350 RTK is the safer primary aircraft.
Does the Matrice 4 replace the Matrice 350 RTK?Does the Matrice 4 replace the Matrice 350 RTK?Does the Matrice 4 replace the Matrice 350 RTK?
For most onshore inspection, mapping and solar work, it can. For offshore wind turbine blades it can't: the heavier airframe, IP55 sealing and larger swappable sensors hold image quality in gusty, humid conditions where a 1.2 kg drone struggles.For most onshore inspection, mapping and solar work, it can. For offshore wind turbine blades it can't: the heavier airframe, IP55 sealing and larger swappable sensors hold image quality in gusty, humid conditions where a 1.2 kg drone struggles.For most onshore inspection, mapping and solar work, it can. For offshore wind turbine blades it can't: the heavier airframe, IP55 sealing and larger swappable sensors hold image quality in gusty, humid conditions where a 1.2 kg drone struggles.
How long does a Matrice 4 battery last on a real inspection?How long does a Matrice 4 battery last on a real inspection?How long does a Matrice 4 battery last on a real inspection?
DJI rates it at 49 minutes of flight and around 42 minutes of hover in still air. In real inspection work, with wind, repositioning and a safe landing reserve, plan for noticeably less, and carry enough batteries to finish a full turbine or site section without rushing.DJI rates it at 49 minutes of flight and around 42 minutes of hover in still air. In real inspection work, with wind, repositioning and a safe landing reserve, plan for noticeably less, and carry enough batteries to finish a full turbine or site section without rushing.DJI rates it at 49 minutes of flight and around 42 minutes of hover in still air. In real inspection work, with wind, repositioning and a safe landing reserve, plan for noticeably less, and carry enough batteries to finish a full turbine or site section without rushing.
